OLV-PGK50 Döner (Rotary) Enkoder, IP67 Paslanmaz Çelik Ağır Hizmet Tipi İçi Boş Mil (Hollow Shaft) Yüksek Hızlı Çalışma ve Zorlu Ortamlar İçin Uygun

Name: OLV-PGK50 Döner (Rotary) Enkoder, IP67 Paslanmaz Çelik Ağır Hizmet Tipi İçi Boş Mil (Hollow Shaft) Yüksek Hızlı Çalışma ve Zorlu Ortamlar İçin Uygun
Brand: OLVO
SKU: T1524
Availability: InStock

Ürün Kodu: T1524

Teklif

PaylaşKoleksiyonFiyat Alarmı

Items	Basic parameters
Brand	SURAL
Encoder type	Incremental encoder
External diameter	50mm
Thickness	18.5mm
Hollow shaft type	Through hole
Hollow shaft diameter	10mm;12mm;14mm;15mm(optional)
Resolution	1000; 1024; 1250; 2000; 2048; 2500; 4096; 5000; 10000
Output phase	Phase A+, B+, Z+, A-, B-, Z-, U+, V+, W+, U-, V-, W-
Supply voltage	DC5V; DC8--30V
Outlet type	Cable out from side
Output mode	Line drive (26LS31)TTL
Output mode	Line drive(DC8-30V)HTL Push-pull
Cable length	1000mm
Consumption current	100mA Max; 120mA Max
Top response frenquency	100kHZ; 500kHZ; 600kHZ
GND	not connect to encoder, must be effectively connected to GND
Slew speed	≤5000rpm
Environmental temperature	Operating: -40~+90℃(repeatable winding cable: -10℃); Storage: -45~+95℃
Enviromental humidity	Operating and storage: 50-85%RH(noncondensing)
Material	Stainless steel
Protection Grade	IP67
Ppackage	Carton box
Net weight	About 150g
