OLV-KN40 Artımlı (Incremental) Enkoder, Geçmeli Delik (Through Hole) Miniyatür Konik Mil, 9,52 mm Mil Çapı, Pozisyon Enkoderi, 5000 PPR Çözünürlük, 4 / 6 / 8 / 10 Kutup, Açı (Angle) Enkoderi

Name: OLV-KN40 Artımlı (Incremental) Enkoder, Geçmeli Delik (Through Hole) Miniyatür Konik Mil, 9,52 mm Mil Çapı, Pozisyon Enkoderi, 5000 PPR Çözünürlük, 4 / 6 / 8 / 10 Kutup, Açı (Angle) Enkoderi
Brand: OLVO
SKU: T1536
Availability: InStock

Ürün Kodu: T1536

Teklif

PaylaşKoleksiyonFiyat Alarmı

Items	Basic parameters
Brand	OLVO
Encoder type	Incremental encoder
External diameter	40mm
Thickness	20mm
Installation dimension	R17mm, R20mm;R23mm
Hollow shaft type	blind hole; through hole, taper hole,solid taper shaft
Solid shaft diameter	10mm (taper shape)
Hollow shaft diameter	6mm;8mm;9mm;9.52mm;10mm
Resolution	1024;2048;2500;3600;5000;7200;10000;14400
Resolution	1000/4;1000/6;1000/8;1024/4;1024/6；1024/8；2000/4；2000/6；2000/8；2048/4；2048/6;2048/8；2500/4；2500/6；2500/8;4096/4;4096/6;4096/8;5000/4;5000/6;5000/8
Output phase	Phase A+,B+,Z+,A-,B-,Z-,U+,V+,W+,U-,V-,W-
Supply voltage	DC5V ; DC8--30V
Outlettype	Cable out from side
Output mode	NPN/PNP(Open Collector Output)
	Voltage output
	Push-pull output
	line drive (26LS31) TTL
	line drive(DC8-30V) HTL
	TTL(DC5V) phase ABZ are back of phase UVW
Protection grade	IP40
Cable length	500mm
Consumption current	100mA MAX
Top response frenquency	300KHZ
Allowable ripple	≤3%rms
Load Voltage	≤DC30V
Insulation strength	AC500V 60s
Insulation resistance	10MΩ
GND	not connect to encoder
Mark to Space ratio	45% to 55%
starting torque	less than 5.9x 10-3 N.m
Intertia moment	less than 1.5x 10-6kg.m2
Shaft load	Radial 30N; Axial 20N
Slew speed	5000RPM
Bearing life	1.5x109 revs at rated load(100000hrs at 2500RPM)
Environmental temperature	Operating:-20 ～+100°C；storage:-25 ～+100°C
Enviromental humidity	Operating and storage: 35-85%RH(noncondensing)
Vibration(endure)	Amplitude 0.75mm,5-55Hz,2 hours for three axis individually
Sock(endure)	490m/s2 ,11 ms three times for X,Y,Z direction individually
Shell Material	Dia cast aluminium
Certification	CE
package	Carton box
Net weight	About 90g (with package)
