OLV-S58 Artımlı (Incremental) Enkoder, Push-Pull Komplementer Çıkış, Alarm / Algılama (Sensing) Özellikli, 58 mm Dış Çap, 10 mm Katı Mil (Solid Shaft), Döner (Rotary) Enkoder, 23040 Pulse’a Kadar Çözünürlük, Pozisyon Enkoderi

Name: OLV-S58 Artımlı (Incremental) Enkoder, Push-Pull Komplementer Çıkış, Alarm / Algılama (Sensing) Özellikli, 58 mm Dış Çap, 10 mm Katı Mil (Solid Shaft), Döner (Rotary) Enkoder, 23040 Pulse’a Kadar Çözünürlük, Pozisyon Enkoderi
Brand: OLVO
SKU: T1528
Availability: InStock

Ürün Kodu: T1528

Teklif

PaylaşKoleksiyonFiyat Alarmı

Items	Basic parameters
Brand	SURAL
Encoder type	Incremental encoder
External diameter	58mm
Thickness	46mm
Installation dimension	Diameter 48mm
Shaft length	19.5mm
Solid Shaft diameter	10mm(D shape)
Resolution	50; 60; 100; 200; 250; 256; 300; 360; 400; 450; 500; 512; 600
	700; 720; 800; 900; 1000; 1024; 1200; 2000; 2048; 2500; 5000
	8192;10000；11520；16384；20000；23040
Output phase	Phase A+,B+,Z+, A- B- Z-
Supply voltage	DC5V; DC8-30V
Outlettype	Cable out from back
	Cable out from side
	Socket out from side
	Socket out from back
Output mode	NPN Collector open circuit output
	Voltage output
	Push-pull output
	Difference output	Long line drive (26LS31)
		compatible RS422
		Long line drive (RT7272)
Protection grade	IP50; IP65
Cable length	1M (cable length could be added appropriately by
	Require, but it need payment individually)
Consumption current	100mA MAX
Top response frenquency	300KHZ
Allowable ripple	≤3%rms
Load Voltage	≤DC30V
Insulation strength	AC500V 60s
Insulation resistance	10MΩ
GND	Not connect to encoder
Mark to Space ratio	45% to 55%
starting torque	less than 10m N.m
Intertia moment	less than 3x 10-6kg.m2
Shaft load	Radial 60N; Axial 40N
Top REV	6000RPM; IP65≤3000r rpm
Bearing life	1.5x109 revs at rated load(100000hrs at 2500RPM)
Environmental temperature	Operating: -20~+80°; storage: -25~+85°
Enviromental humidity	Operating and storage: 35-85%RH(noncondensing)
Vibration(endure)	Amplitude 0.75mm,5-55Hz,2 hours for three axis individually
Sock(endure)	490m/s2, 11 ms three times for X, Y, Z direction individually
Shaft Material	Stainless steel
Shell Material	Dia cast aluminium
Cable length	1000mm(cable with shielding)
Certification	CE
package	Carton box
Net weight	AbouT 420g (with package)
