OLV-ST58 Konik Mil (Tapered Shaft) 9,25 mm, 1024 PPR / 2048 PPR, 1 Vpp / 1 Vss, Analog ve Dijital Sinyal Çıkışlı, Sin/Cos (Sincos) Artımlı (Incremental) Enkoder, Optik Enkoder

Name: OLV-ST58 Konik Mil (Tapered Shaft) 9,25 mm, 1024 PPR / 2048 PPR, 1 Vpp / 1 Vss, Analog ve Dijital Sinyal Çıkışlı, Sin/Cos (Sincos) Artımlı (Incremental) Enkoder, Optik Enkoder
Brand: OLVO
SKU: T1522
Availability: InStock

Ürün Kodu: T1522

Teklif

PaylaşKoleksiyonFiyat Alarmı

Items	Basic parameters
Brand	SURAL
Encoder type	Sincos incremental encoder
External diameter	58mm
Thickness	38.2mm
Shaft type	Taper shaft
Taper shaft diameter	9.25mm
Resolution	1024-2048(Sin/Cos)
Supply voltage	DC5V ； DC8-30V
Signal	1Vpp(differential)
	After differential generation Sin/Cos (DC5V; DC8-30V)
	Before differential generation Sin/Cos (DC5V)
Protection grade	IP40
Reverse polarity protection	√
Short-circuit protection	√
Shell material	Aluminum alloy
Shaft material	Stainless steel
Net weight	About 240g (with package)
Mark to space ratio	45% to 55%
Allowable shaft force	Radial 30N; Axial 20N
Reference point signal	One
Certification	CE
package	Carton box
