OLV-Z100 Artımlı (Incremental) Enkoder, Döner Pozisyon Enkoderi, CW / CCW (Saat Yönü / Ters Yön) Kare Dalga Çıkışı, 2500 PPR – 10000 PPR Çözünürlük, Esnek Flat Kablo (FFC) – 14 Pin, ABZUVW Sinyal Çıkışlı Enkoder

Name: OLV-Z100 Artımlı (Incremental) Enkoder, Döner Pozisyon Enkoderi, CW / CCW (Saat Yönü / Ters Yön) Kare Dalga Çıkışı, 2500 PPR – 10000 PPR Çözünürlük, Esnek Flat Kablo (FFC) – 14 Pin, ABZUVW Sinyal Çıkışlı Enkoder
Brand: OLVO
SKU: T1532
Availability: InStock

Ürün Kodu: T1532

Teklif

PaylaşKoleksiyonFiyat Alarmı

Items	Basic parameters
Brand	SURAL
Encoder type	Bearingless encoder
External diameter	100mm
Thickness	16mm
Hollow shaft type	Through hole
Hollow shaft diameter	40mm; 63mm; 65mm
Resolution	2500/8; 2500/10; 2500/16; 5000/10; 5000/16
Resolution	10000/8; 10000/10; 10000/16
Output phase	A+, B+, Z+, A-, B-, Z-, U+, V+, W+, U-, V-, W-
Supply voltage	DC5V; DC8--30V
Output mode	Radial cable
	Radial socket
	Line drive(26LS31)TTL
	Line drive(DC8-30V)HTL
Cable length	300mm
Rise/fall time	Less than 1 us(cable length: 2 meters)
Consumption current	120mA MAX
Top response frenquency	300KHZ
GND	Not connect to encoder
Slew speed	5000rpm
Environmental temperature	Operating: -20 ～ +80°; storage: -25 ～ +90°
Enviromental humidity	Operating and storage: 35-85%RH(noncondensing)
Material	Aluminium alloy
Certification	CE
package	Carton box
Net weight	About 180g (with package)
