OLV-Z48 Artımlı (Incremental) Enkoder, 8 mm Geçmeli Delik (Through Hole), Düşük Maliyetli, Kolay Montaj, Maks. 2500 PPR, ABZUVW Faz Çıkışları, Ekstra İnce Yapı, Ölçüm Cihazları İçin Uygun Enkoder

Name: OLV-Z48 Artımlı (Incremental) Enkoder, 8 mm Geçmeli Delik (Through Hole), Düşük Maliyetli, Kolay Montaj, Maks. 2500 PPR, ABZUVW Faz Çıkışları, Ekstra İnce Yapı, Ölçüm Cihazları İçin Uygun Enkoder
Brand: OLVO
SKU: T1535
Availability: InStock

Ürün Kodu: T1535

Teklif

PaylaşKoleksiyonFiyat Alarmı

Items	Basic parameters
Brand	OLVO
Encoder type	Bearingless encoder
External diameter	48mm
Thickness	22.5mm
Hollow shaft type	Through hole
Hollow shaft diameter	8mm
Resolution	50;60;100;200;250;256;300;360;400;450;500;512;600;1000;1024;1200;2000;2048;2500;
	1000/4;1000/6;1000/8;1024/4;1024/6；1024/8；2048/4；
	2048/6;2048/8；2500/4；2500/6；2500/8;
Output phase	Phase A+, B+, Z+, A-, B-, Z-, U+, V+, W+, U-, V-, W-
Supply voltage	DC5V; DC8--30V
Outlet type	Cable out from side
Output mode	NPN/(Open Collector Output)
	Line drive (26LS31)TTL
	Line drive(DC8-30V)HTL
Cable length	300mm
Consumption current	120mA MAX
Top response frenquency	300KHZ
GND	Not connect to encoder
Slew speed	5000rpm
Environmental temperature	Operating: -20 ～+80°; storage: -25 ～+90°
Enviromental humidity	Operating and storage: 35-85%RH(noncondensing)
Material	Aluminium alloy
Certification	CE
Ppackage	Carton box
Net weight	About 60g (with package)
